** CALL FOR PRICING **
ENGINE:
Model: 3A165LWM-U4
Engine Manufacturer: KIOTI
24.50 hp (18.20 kW)
Displacement: 100.50 cu. in. (1,647 cc)
RPM
Fuel Type: Diesel
Aspiration: Intercular
Fuel Capacity: 9 gal (34 L)
TRANSMISSION:
Transmission: Hydrostatic
Shuttle: Dry Single Stage
Main Gear: Dry Single Stage
Travel Speeds Forward: 3 Ranges, w/ infinite speeds
Travel Speeds Reverse: 3 Ranges, w/ infinite speeds
Travel Speeds Minimum Speed: 0.75 mph (1.21 km/h)
Travel Speeds Maximum Speed: 10.01 mph (16.11 km/h)
Travel Speeds Min Reverse Speed: 0 mph (0 km/h)
Travel Speeds Max Reverse Speed: 11.28 mph (7 km/h)
PTO:
PTO Type: Live
PTO Power: 18.70 hp (13.90 kW)
Rear Speed: 540 rpm
Mid Speed: 2,000 rpm (Optional)
DRIVE TRAIN:
Brakes: Wet Multi Disc
Clutch; Dry Single Stage
Steering: Mechanical
HYDRAULICS:
Pump: Gear
Pump Capacity: 11.70 gpm (44.40 lpm)
Lift Capacity: 1,631 lb (740 kg)
HITCH:
Type: Three Point
Category: Category 1
Control Type: Position
Lift Capacity: 1,500 lb (680 kg)
DIMENSIONS:
Width: 54.50 in (1,385 mm)
Height: 92.90 in (2,360 mm)
Wheelbase: 65.70 in (1,670 mm)
Ground Clearance: 13.40 in (340 mm)
Front Tread: 48.20 in (1,225 mm)
Rear Tread: 47.60 in (1,210 mm)
Turning Radius: 8.96 ft (2.73 m)
Weight: 2,689 lb (1,220 kg)
Length with Hitch: 120.90 in (3,070 mm)
ADDED OPTIONS:
Front & Rear Ind. Tire Assemblies
Rubber Deck Mat
Battery
KL4030C Loader Pkg w/66" QA Bucket & Grill Guard
