** CALL FOR PRICING **
ENGINE:
Model: 3HT-S4TH45A
Engine Manufacturer: KIOTI
Power: 45 hp (33.60 kW)
Displacement: 111.40 cu. in. (1,826 cc)
2,600 rpm
Fuel Type: Diesel
Fuel Capacity: 13.20 gal (50 L)
TRANSMISSION:
Hydrostatic
Shuttle: Hydrostatic
Main Gear: Hydrostatic
Travel Speeds Forward: 3 Ranges w/ Infinite Speeds
Travel Speeds Reverse: 3 Ranges w/ Infinite Speeds
Maximum Speed: 28.10 mph (17.50 km/h)
Max Reverse Speed: 19.70 mph (12.20 km/h)
PTO:
Type: Independent
Power: 50.80 hp (37.90 kw)
Rear Speed: 540
Mid Speed: 2,000 (optional)
DRIVE TRAIN:
Wet Disc Type Brakes
No Clutch
Hydrostatic Power Steering
HYDRAULICS:
No Pump
Pump Capacity: 16.50 gpm (62.40 lpm)
Lift Capacity: 2,940 lb (1,334 kg)
HITCH:
3-Point
Category 2
Position w/Draft Control
2,940 lb Lift (1,334 kg)
DIMENSIONS:
Length with Hitch: 136.40 in (3,465 mm)
Width: 70.40 in (1,789 mm)
Wheelbase Length: 75.50 in (1,918 mm)
Ground Clearance: 11.80 in (300 mm)
Front Tread: 51.30 in (1,303 mm)
Rear Tread: 56.90 in (1,444 mm)
Turning Radius: 11.16 ft (3.40 m)
Weight: 4,422 lb (2,006 kg)
Height: 93.70 in (2,380 mm)
ADDED OPTIONS:
Left & Right Front and Rear R-14 Tire Assemblies
Battery
KL5810 Loader pkg w/72" QA Bucket & Grill Guard
