** CALL FOR PRICING **
ADDED FEATURES
R14 Tires
KL4030 Loader
66" QA Bucket
Grill Guard
FEATURES
Engine Gross Power: 39.6 hp (29.5 kW)
PTO Type: Live
Transmission Type: Hydrostatic
Shuttle: Dry Single Stage
KIOTI Diesel Engine
Dual Pedal HST
Power Steering
Foldable ROPS
High Capacity Hydraulic Pump
Single Lever Joystick
STANDARD EQUIPMENT
Rear PTO
Wet Multi Disc Brakes
Joystick Valve
Drawbar
Headlights
Parking Brake
PTO Shield
INSTRUMENT PANEL
Digital Hour Meter
Coolant Temperature Gauge
Electrical Tachometer
Fuel Gauge
Engine Oil Pressure Light
High Beam, Emergency Flasher, Direction Indicators
Glow Plug Light
Alternator Light
SPECIFICATIONS
Transmission
Transmission Type: HST
Main Gear: Manual
No. of Travel Speeds - Forward / Reverse: Infinite, 3 Range
Min. Travel Speed of Forward w/ Ag @ Engine rated speed: 0 mph (0 km/h)
Max. Travel Speed of Forward w/ Ag @ Engine rated speed: 14.85 mph (23.91 km/h)
Power Take-Off
PTO Type Trans: Live
PTO Power: 33.3 hp (24.8 kW)
Rear PTO Speeds (1st): 540 rpm
Mid PTO Speeds: 2,000 rpm (Optional)
Brakes and Clutch
Brakes: Wet Multi Disc
Clutch: Dry Single Stage
Dimensions w/ AG Tire
Length w/ 3-point hitch: 120.9 in. (3,070 mm)
Width: 54.5 in. (1,385 mm)
Height from Top of ROPS: 92.91 in. (2,520 mm)
Wheelbase: 65.7 in. (1,670 mm)
Ground Clearance: 13.4 in. (340 mm)
Front Tread Ag Tires - Min: 48.2 in (1,225 mm)
Rear Tread Ag Tires - Min: 47.6 in. (1,210 mm)
Min. Turning Radius w/ Brake: 107.48 in. (2,730 mm)
Hydraulics
Total Pump Flow: 11.7 gpm (44.4 L/min)
3-Point Hitch
Standard Category: Category 1
Maximum Lifting Capacity (24"aft. of hitch): 1,631 lbs. (740 kg)
Control Type: Position
Weight
Weight w/ Ag Tires w/ ROPS: 2,734 lbs. (1,240 kg)
